Description
The IM 230-3 is the perfect partner for steel welding, aluminum welding, and MIG soldering. This 2-burner MIG/MAG inverter welding system offers synergy-regulated technology for maximum precision and user-friendliness.
With the intuitive 2-button control, switching between different welding processes is effortless. The powerful welding current of up to 200 A and the modern 230 V inverter technology ensure top-notch results. The 3-burner system allows for the connection of up to two gas cylinders, while the connection for a spool gun expands the range of applications.
Equipped with:
1 x 308115 Spool-Gun torch
2 x 337220 Wire feed rollers | steel | 0.8 mm & 1.0 mm
1 x 308102 Torch Force 200 | MIG soldering (CuSi3) | 3.0 m
1 x 308103 Torch Force 200 | Steel welding | 3.0 m
1 x ground cable with clamp | 4 m
2 x connection cable for shielding gas
1 x pressure cylinder holder for 2 × 20 liters
1 x operating instructions
| Current setting range: | 20 – 200 A |
|---|---|
| Effectiveness: | 83 % , 83 % |
| Fuse: | 16 A (slow) |
| Length × width × height: | 1030 x 640 x 880 mm |
| Mains connection (Cu): | 3 × 2,5 mm² |
| Mains voltage: | 1 ~ 230 V |
| Mark of conformity: | CE |
| Open circuit voltage: | 40,22 V |
| Operating temperature: | -10 bis 40 °C |
| Power factor: | 0,75 |
| Protection class: | IP 23 |
| Sound pressure level: | 67 dB(A) |
| Voltage setting range: | 10 – 35 V |
| Weight: | 50 kg |
| Wire speed range: | 1,5 – 20 m/min |
